- Case report
- Open Access
Pulmonary infection due to fluoroquinolone-resistant Mycolicibacterium fortuitum: a case report
BMC Infectious Diseases volume 20, Article number: 866 (2020)
Mycolicibacterium fortuitum is a species of the rapidly growing mycobacteria that can cause pulmonary infection. It is susceptible to multiple antibiotics both in vitro and in clinical practice, so that any combination of susceptible drugs is effective. However, we encountered a case of infection due to fluoroquinolone-resistant M. fortuitum. In this study, we report the case and describe the mechanism of resistance.
A 65-year-old man with a history of total gastrectomy and immunosuppressant treatment for rheumatoid arthritis developed a recurrence of pulmonary infection caused by M. fortuitum. He was treated with clarithromycin and levofloxacin as a first-line treatment, based on the favorable susceptibility at that time. After recurrence, a high minimum inhibitory concentration to fluoroquinolones was detected. DNA sequencing of the pathogen showed the substitution of serine for tryptophan at residue 83 in the gyrA gene. He was successfully treated with a combination of other antibiotics.
This is the first report on the treatment of fluoroquinolone-resistant M. fortuitum and investigation of the mechanism of resistance. We suggest that the susceptibility test remains effective for determining the next line of treatment after a pathogen has acquired resistance, and resistance to fluoroquinolones in M. fortuitum can be attributed to a single change of amino acid.
Non-tuberculous mycobacteria (NTM) are widespread in the natural environment, including natural waters, engineered water systems, and soils . They can affect many organs and cause diseases, such as pulmonary disease, lymphadenitis, cutaneous disease, and disseminated disease . Of these, pulmonary infection is the most common clinical manifestation . The most common pathogens for lung disease are Mycobacterium avium complex and Mycobacteroides abscessus, but Mycolicibacterium fortuitum is also important . M. fortuitum is one of the rapidly growing mycobacteria (RGM), which is the categorization according to colony morphology and growth characteristics . One characteristic of M. fortuitum is to show favorable susceptibility and clinical effect of multiple antibiotics . The 2007 official American Thoracic Society (ATS)/Infectious Diseases Society of America (IDSA) statement showed that M. fortuitum isolates were susceptible to amikacin (100%), ciprofloxacin and ofloxacin (100%), sulfonamides (100%), cefoxitin (50%), imipenem (100%), clarithromycin (80%), and doxycycline (50%) . Several previous cases have reported that combining antibiotics, including quinolones, successfully completed the treatment [5, 6]. There is no report about the treatment of resistant M. fortuitum.
Quinolones act by inhibiting the bacterial topoisomerases DNA gyrase and topoisomerase IV . The most common mechanism of quinolone resistance in mycobacteria is due to mutations in the gyrA and gryB genes of DNA gyrase . These mutations involved a conserved region called the quinolone resistance-determining regions (QRDR) . However, there have been no reports on M. fortuitum and its mechanism of resistance.
We describe a rare case of pulmonary disease due to fluoroquinolone-resistant M. fortuitum. In addition, we investigate the mechanism of resistance of M. fortuitum.
A 65-year-old man (height 166.1 cm, weight 63.0 kg) with a history of total gastrectomy for gastric cancer was admitted to our hospital with complaints of cough, sputum, and fever. At 61 years of age, he was diagnosed with rheumatoid arthritis. He underwent surgical lung biopsy for evaluation of a 3-year history of unchanged reticular shadow observed in his chest. Histopathological analysis showed uniform involvement of alveolar wall fibrosis with lymphoid follicles, which was consistent with a diagnosis of collagen vascular disease-associated interstitial pneumonia (CVD-IP). Tacrolimus (1 mg/day) and salazosulfapyridine (1000 mg/day) were started to treat the rheumatoid arthritis.
At 63 years of age, we found pulmonary consolidation in the left middle and lower lung field on chest radiograph and was more striking, especially in left upper lobe on computed tomography (Fig. 1a), despite adding 30 mg of prednisolone (PSL) for the progression of CVD-IP. Bronchoscopy was performed for detecting pathogen, and the microscopic examinations of sputum and bronchial lavage smear stained with the Ziehl-Neelsen staining technique scored a grade of 2 respectively. Moreover, M. fortuitum identified by matrix-assisted laser-desorption/ionization time-of-flight mass spectrometry was isolated from the bronchial lavage specimen. Susceptibility testing was performed according to Clinical and Laboratory Standard Institute guideline M24 3rd Edition , using a broth microdilution method and cation-adjusted Mueller-Hinton broth. We prescribed clarithromycin (600 mg/day) and levofloxacin (500 mg/day) based on the result of susceptibility tests (Table 1). The dose of clarithromycin was determined considering the efficacy and the risk of gastrointestinal toxicity because he had esophageal reflux after total gastrectomy. The consolidations improved gradually (Fig. 1b). Antibiotic treatment was discontinued 12 months after sputum cultures yielded negative results, and the dosage of PSL for CVD-IP was tapered to 15 mg.
However, only 1 month after the end of the antibiotic treatment, pulmonary consolidation in the left lung and middle lung field worsened again, and new consolidation occurred in the right middle lung field. Despite increasing PSL to 40 mg and re-administration of clarithromycin and levofloxacin, his cough and sputum worsened, and his body temperature persisted over 38 °C. Six months after the end of the initial antibiotic treatment, we admitted him for further examinations and intravenous antibiotic therapy. On admission, he was ill-appearing and febrile to 37.5 °C with an oxygen saturation of 96% on room air. His chest auscultation revealed coarse crackles over the inferior zone of the lungs. Laboratory examinations revealed an increased white blood cell count of 15,900/μL and elevated C-reactive protein level 4.45 mg/dL. Sialylated carbohydrate antigen KL-6, surfactant protein-D, anti-cyclic citrullinated peptide antibody, and matrix metalloproteinase-3 were 803 U/mL, 112 mg/mL, 14.4 U/mL, and 791.7 mg/mL, respectively. These levels of serum markers for interstitial pneumonia and rheumatoid arthritis were high but remained unchanged for several months. A chest radiograph showed that consolidation was widespread. A chest computed tomography scan showed consolidations in the bilateral upper and middle lobe predominance (Fig. 1c). Although we confirmed Ziehl-Neelsen stained smear samples of sputum and bronchial lavage scored the grade of 2 and detected M. fortuitum from both sputum culture and bronchial lavage culture, its susceptibility differed from the previous one. It demonstrated minimum inhibitory concentration (MIC) > 4 mg/L to ciprofloxacin and levofloxacin (Table 1). Intravenous administrations of amikacin (900 mg/three-times-weekly) and imipenem/cilastatin (1500 mg/day), and oral administrations of clarithromycin and sitafloxacin (100 mg/day) were started based on the result of antimicrobial susceptibility testing. His symptoms and chest imaging improved gradually (Fig. 1d and e). The intravenous imipenem/cilastatin treatment course was completed, and he was discharged four weeks after administration. In an outpatient setting, clarithromycin, sitafloxacin, and three-times-weekly amikacin were continued. Moreover, faropenem (600 mg/day) and trimethoprim-sulfamethoxazole (trimethoprim 320 mg/day and sulfamethoxazole 1600 mg/day) were added after discharge, despite faropenem has no certain evidence of efficacy for M. fortuitum. Because we have very limited options for antibiotics to replace imipenem infusions in Japan. Although amikacin was discontinued after 11 months because auditory dysfunction appeared, not only his symptoms for infection but also the consolidation in chest x-ray did not get worse for 10 months after amikacin discontinuation. Over time, his PSL gradually diminished as his arthritis symptoms also improved.
The DNA gyrase gene of M. fortuitum was sequenced. Chromosomal DNA was extracted by the freezing-boiling technique of Woods and Cole, as previously described . DNA fragments corresponding to the QRDR of GyrA were amplified by polymerase chain reaction using previously described primers Pri9 (5′-CGCCGCGTGCTGCATGCAGATG-3′) and Pri8 (5′-CTGGTGGAGTCAGT TA/GCCC/TGGCGA-3′) . We tested M. fortuitum DNA gyrase from both before and after the treatment with clarithromycin and levofloxacin. The amino acid at residue 83 of the gyrA gene changed from serine to tryptophan (Fig. 2 and Table 2).
Discussion and conclusions
To our knowledge, this is the first report to describe the treatment of fluoroquinolone-resistant M. fortuitum and identify the mechanism. M. fortuitum is one of RGM , commonly seen as an infection through whirlpool footbaths in nail salons [11,12,13,14]. It most commonly causes localized infections of the skin, bone, and soft tissue disease . While pulmonary disease due to M. fortuitum is relatively rare , some risk factors have been reported. Related structural lung diseases such as chronic obstructive pulmonary disease and bronchiectasis, neoplasms, immunosuppressant use, and environmental exposure are known to be risk factors in other NTM-related pulmonary diseases . Gastrointestinal disturbance with chronic vomiting is also a characteristic predisposing factor for M. fortuitum . Our patient had many risk factors including current use of an immunosuppressant, previously treated neoplasms, and having a gastrointestinal disorder secondary to a total gastrectomy.
Treatment of NTM is based on their unique susceptibility patterns and sensitivities to antibiotics . M. fortuitum is one of the most susceptible groups in vitro, which closely corresponds to the clinical effect. Therefore, using at least two antibiotics based on susceptibility test is recommended and the duration of treatment should be given for at least 12 months after negative sputum culture is obtained . Any two-drug combination with in vitro susceptibility should be successful . In particular, resistance to fluoroquinolones is quite rare [16,17,18,19]; therefore, fluoroquinolones are recommended as a treatment option for M. fortuitum . Since it is rare to acquire resistance in M. fortuitum, there is no report on treating it. In our case, the result of susceptibility test in vitro even after acquiring resistance was also parallel to those of clinical effect. The antibiotics which showed high MIC became clinically ineffective. Moreover, treatment with amikacin and imipenem/cilastatin succeeded, as susceptibility test indicated. Therefore, we suggest that susceptibility test is still a valid metric to choose antibiotics in patients who have been previously treated.
As far as we know, the mechanism of resistance to fluoroquinolones in M. fortuitum has never been reported. Quinolones inhibit both bacterial DNA gyrase and topoisomerase IV in other bacteria, whereas DNA gyrase is the only target in mycobacteria . This enzyme is a tetrameric protein composed of two A and two B subunits, carrying gyrA and gyrB gene products respectively . One mechanism of resistance is associated with a difference in the structures of subunits, including only a single amino acid change in these genes . Several amino acids are reported to be related to quinolone resistance, which commonly localizes in the limited regions, called the QRDR . Using in the numbering system used for Escherichia coli, the residue at position 83 in the QRDR GyrA plays an important role . Although most quinolone-resistant species such as M. abscessus or M. avium have an alanine residue at position 83 in GyrA, wild-type M. fortuitum GyrA has a serine which is the same structure as quinolone-susceptible bacteria such as E. coli and Neisseria gonorrhoeae . In our case, a strain before antibiotic treatment had a serine residue at position 83 in the A subunit of DNA gyrase, as same as wild-type M. fortuitum. However, after treatment with clarithromycin and levofloxacin, a serine was substituted by a tryptophan. We hypothesize that the conversion of a small polar amino acid to a large hydrophobic residue leads to quinolone resistance in this case. This hypothesis is supported by an analysis of E. coli GyrA, which showed that this change can cause quinolone resistance . Unfortunately, in our case, it was difficult to accurately distinguish between recurrence due to acquisition of quinolone resistance and reinfection of quinolone-resistant strain because no molecular typing tests were performed. However, the infection was suspected to have recurred because it worsened just 1 month after the antibiotics were discontinued.
Although a certain breakpoint has not been established for sitafloxacin, M. fortuitum was reported to have low MIC to sitafloxacin . Recent studies showed that ciprofloxacin or levofloxacin-resistant strains with GyrA mutations remain low MIC to sitafloxacin in N. gonorrhoeae, Mycobacterium tuberculosis, and M. avium complex [22,23,24]. Whereas study in Helicobacter pylori infection after unsuccessful eradication with sitafloxacin-containing regimens showed that sitafloxacin might lead to the accumulation of double mutations in GyrA, which would provide resistance to sitafloxacin in Helicobacter pylori . The present case also showed low MIC to sitafloxacin in strains with ciprofloxacin and levofloxacin-resistance (Table 1). Further study is needed for the investigation of that mechanism and clinical efficacy of sitafloxacin, as it could be a candidate as a suitable option because a variety of oral treatment for RGM is limited.
The official statement by ATS/IDSA in 2007 recommended that clarithromycin for RGM should be used with caution . It is mainly because of the presence of the erythromycin-inducible methylase (erm) gene, which methylates the 23S ribosomal RNA macrolide-binding site, well-known as a common cause of inducible resistance to macrolides . Some RGM species have their own intrinsic erm gene, such as the erm (39) genes of M. fortuitum or the erm (41) genes of M. abscessus. Due to the erm gene, isolates became resistant to clarithromycin with 14 days of incubation, although these showed the susceptible MICs at 3 days of incubation . Our case showed susceptibility at day 3, but resistance at day 14 to clarithromycin (Table 1). Because of limited choices of oral antibiotics and the potency of these combinations of antibiotics, we did not discontinue clarithromycin. Although how to use clarithromycin for RGM is still controversial, further studies are required to evaluate the effect of combination therapy to increase options for the treatment of RGM.
In conclusion, this is the first report to describe the treatment of a pulmonary infection due to fluoroquinolone-resistant M. fortuitum. Although it has been reported as one of treatable species in mycobacterium, it can become resistant to fluoroquinolones. Susceptibility test is still effective over second-line treatment. Moreover, a single amino acid substitution in DNA gyrases can lead to resistance, even in M. fortuitum.
Availability of data and materials
Data sharing is not applicable to this article as no datasets were generated or analyzed during this case report.
Collagen vascular disease-associated interstitial pneumonia
- erm :
Minimum inhibitory concentration
Quinolone resistance determining region
Rapid growing mycobacteria
Falkinham JO 3rd. Surrounded by mycobacteria: nontuberculous mycobacteria in the human environment. J Appl Microbiol. 2009;107(2):356–67. https://doi.org/10.1111/j.1365-2672.2009.04161.x.
Koh WJ. Nontuberculous Mycobacteria-Overview. Microbiol Spectr. 2017;5(1). https://doi.org/10.1128/microbiolspec.TNMI7-0024-2016.
Prevots DR, Shaw PA, Strickland D, Jackson LA, Raebel MA, Blosky MA, Montes de Oca R, Shea YR, Seitz AE, Holland SM, et al. Nontuberculous mycobacterial lung disease prevalence at four integrated health care delivery systems. Am J Respir Crit Care Med. 2010;182(7):970–6. https://doi.org/10.1164/rccm.201002-0310OC.
Griffith DE, Aksamit T, Brown-Elliott BA, Catanzaro A, Daley C, Gordin F, Holland SM, Horsburgh R, Huitt G, Iademarco MF, et al. An official ATS/IDSA statement: diagnosis, treatment, and prevention of nontuberculous mycobacterial diseases. Am J Respir Crit Care Med. 2007;175(4):367–416. https://doi.org/10.1164/rccm.200604-571ST.
Fabbian F, De Giorgi A, Pala M, Fratti D, Contini C. Pleural effusion in an immunocompetent woman caused by Mycobacterium fortuitum. J Med Microbiol. 2011;60(Pt 9):1375–8. https://doi.org/10.1099/jmm.0.024737-0.
Sunwoo BY. An oesophageal and pulmonary association not to forget. Thorax. 2017;72(5):485–6. https://doi.org/10.1136/thoraxjnl-2016-209045.
Guillemin I, Jarlier V, Cambau E. Correlation between quinolone susceptibility patterns and sequences in the a and B subunits of DNA gyrase in mycobacteria. Antimicrob Agents Chemother. 1998;42(8):2084–8.
Woods GL, Wengenack NL, Lin G, Brown-Elliott BA, Cirillo DM, Conville PS, Desmond EP, Killian SB, Parrish NM, Pfeltz R, et al. Susceptibility testing of mycobacteria, Nocardiae, and other aerobic Actinomycetes, 3rd ed. CLSI standard M24. Wayne: Clinical and Laboratory Standard Institute; 2018.
Woods SA, Cole ST. A rapid method for the detection of potentially viable Mycobacterium leprae in human biopsies: a novel application of PCR. FEMS Microbiol Lett. 1989;53(3):305–9. https://doi.org/10.1016/0378-1097(89)90235-8.
Guillemin I, Cambau E, Jarlier V. Sequences of conserved region in the a subunit of DNA gyrase from nine species of the genus Mycobacterium: phylogenetic analysis and implication for intrinsic susceptibility to quinolones. Antimicrob Agents Chemother. 1995;39(9):2145–9. https://doi.org/10.1128/aac.39.9.2145.
Sniezek PJ, Graham BS, Busch HB, Lederman ER, Lim ML, Poggemyer K, Kao A, Mizrahi M, Washabaugh G, Yakrus M, et al. Rapidly growing mycobacterial infections after pedicures. Arch Dermatol. 2003;139(5):629–34. https://doi.org/10.1001/archderm.139.5.629.
Vugia DJ, Jang Y, Zizek C, Ely J, Winthrop KL, Desmond E. Mycobacteria in nail salon whirlpool footbaths, California. Emerg Infect Dis. 2005;11(4):616–8. https://doi.org/10.3201/eid1104.040936.
Winthrop KL, Abrams M, Yakrus M, Schwartz I, Ely J, Gillies D, Vugia DJ. An outbreak of mycobacterial furunculosis associated with footbaths at a nail salon. N Engl J Med. 2002;346(18):1366–71. https://doi.org/10.1056/NEJMoa012643.
Winthrop KL, Albridge K, South D, Albrecht P, Abrams M, Samuel MC, Leonard W, Wagner J, Vugia DJ. The clinical management and outcome of nail salon-acquired Mycobacterium fortuitum skin infection. Clin Infect Dis. 2004;38(1):38–44. https://doi.org/10.1086/380459.
Prevots DR, Marras TK. Epidemiology of human pulmonary infection with nontuberculous mycobacteria: a review. Clin Chest Med. 2015;36(1):13–34. https://doi.org/10.1016/j.ccm.2014.10.002.
Aono A, Morimoto K, Chikamatsu K, Yamada H, Igarashi Y, Murase Y, Takaki A, Mitarai S. Antimicrobial susceptibility testing of Mycobacteroides (Mycobacterium) abscessus complex, Mycolicibacterium (Mycobacterium) fortuitum, and Mycobacteroides (Mycobacterium) chelonae. J Infect Chemother. 2019;25(2):117–23. https://doi.org/10.1016/j.jiac.2018.10.010.
Esteban J, Martin-de-Hijas NZ, Ortiz A, Kinnari TJ, Bodas Sanchez A, Gadea I, Fernandez-Roblas R. Detection of lfrA and tap efflux pump genes among clinical isolates of non-pigmented rapidly growing mycobacteria. Int J Antimicrob Agents. 2009;34(5):454–6. https://doi.org/10.1016/j.ijantimicag.2009.06.026.
Hatakeyama S, Ohama Y, Okazaki M, Nukui Y, Moriya K. Antimicrobial susceptibility testing of rapidly growing mycobacteria isolated in Japan. BMC Infect Dis. 2017;17(1):197. https://doi.org/10.1186/s12879-017-2298-8.
Santos DR, Lourenco MC, Coelho FS, Mello FC, Duarte RS. Resistance profile of strains of Mycobacterium fortuitum isolated from clinical specimens. J Bras Pneumol. 2016;42(4):299–301. https://doi.org/10.1590/S1806-37562016000000073.
Hooper DC, Jacoby GA. Mechanisms of drug resistance: quinolone resistance. Ann N Y Acad Sci. 2015;1354:12–31. https://doi.org/10.1111/nyas.12830.
Yoshida H, Bogaki M, Nakamura M, Nakamura S. Quinolone resistance-determining region in the DNA gyrase gyrA gene of Escherichia coli. Antimicrob Agents Chemother. 1990;34(6):1271–2. https://doi.org/10.1128/aac.34.6.1271.
Hamasuna R, Ohnishi M, Matsumoto M, Okumura R, Unemo M, Matsumoto T. In vitro activity of Sitafloxacin and additional newer generation Fluoroquinolones against ciprofloxacin-resistant Neisseria gonorrhoeae isolates. Microb Drug Resist. 2018;24(1):30–4. https://doi.org/10.1089/mdr.2017.0054.
Yi L, Aono A, Chikamatsu K, Igarashi Y, Yamada H, Takaki A, Mitarai S. In vitro activity of sitafloxacin against Mycobacterium tuberculosis with gyrA/B mutations isolated in Japan. J Med Microbiol. 2017;66(6):770–6. https://doi.org/10.1099/jmm.0.000493.
Asakura T, Suzuki S, Fukano H, Okamori S, Kusumoto T, Uwamino Y, Ogawa T, So M, Uno S, Namkoong H, et al. Sitafloxacin-Containing Regimen for the Treatment of Refractory Mycobacterium avium Complex Lung Disease. Open Forum Infect Dis. 2019;6(4):ofz108. https://doi.org/10.1093/ofid/ofz108.
Mori H, Suzuki H, Matsuzaki J, Masaoka T, Kanai T. Acquisition of double mutation in gyrA caused high resistance to sitafloxacin in helicobacter pylori after unsuccessful eradication with sitafloxacin-containing regimens. United European Gastroenterol J. 2018;6(3):391–7. https://doi.org/10.1177/2050640617737215.
Brown-Elliott BA, Nash KA, Wallace RJ Jr. Antimicrobial susceptibility testing, drug resistance mechanisms, and therapy of infections with nontuberculous mycobacteria. Clin Microbiol Rev. 2012;25(3):545–82. https://doi.org/10.1128/CMR.05030-11.
Brown-Elliott BA, Philley JV. Rapidly Growing Mycobacteria. Microbiol Spectr. 2017;5(1). https://doi.org/10.1128/microbiolspec.TNMI7-0027-2016.
We would like to thank Editage (www.editage.com) for English language editing.
Ethics approval and consent to participate
While institutional ethical approval was not required for this case report, the patient provided informed consent for the publication of this report.
Consent for publication
Written informed consent was obtained from the patient for publication of any potentially identifying images and clinical details of this case report.
The authors declare no conflicts of interest in association with the present study.
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
About this article
Cite this article
Kurokawa, K., Harada, N., Sasano, H. et al. Pulmonary infection due to fluoroquinolone-resistant Mycolicibacterium fortuitum: a case report. BMC Infect Dis 20, 866 (2020). https://doi.org/10.1186/s12879-020-05596-1
- Mycolicibacterium fortuitum
- DNA gyrase
