RS3PE syndrome developing during the course of probable toxic shock syndrome: a case report

Abstract

Background

Remitting seronegative symmetrical synovitis with pitting edema (RS3PE) is a rare syndrome characterized by “remitting,” “seronegative” (namely rheumatoid factor-negative), and “symmetrical” synovitis with pitting edema on the dorsum of the hands and feet. Recently, there have been reports that serum vascular endothelial growth factor (VEGF) is elevated in this condition.

Case presentation

An 85-year-old man visited our department with a rash that had appeared 2 days earlier and a fever that had developed on the day of his visit. Based on clinical findings of fever, erythema exudativum multiforme, transitory hypotension, conjunctiva hyperemia, elevated creatine kinase, and desquamation, we suspected toxic shock syndrome (TSS). Therefore, we started treatment with vancomycin (1 g/day) and clindamycin (600 mg/day), after which his fever rapidly remitted. However, pitting edema on the dorsum of his hands and feet appeared on day 7, and the patient also had painful wrist and ankle joints. Additional tests were negative for rheumatoid factor, and anti-cyclic citrullinated protein antibodies were < 0.2 U/mL. Further, serum matrix metalloproteinase-3 (199.6 ng/mL; reference value ≤123.8 ng/mL) and serum VEGF (191 pg/mL; reference value ≤38.3 pg/mL) levels were elevated, and human leukocyte antigen-A2 was detected. The patient was thus diagnosed with RS3PE syndrome, for which he satisfied all four diagnostic criteria: 1) pitting edema in the limbs, 2) acute onset, 3) age ≥ 50 years, and 4) rheumatoid factor negativity. He was treated with oral prednisolone, resulting in the normalization of his serum VEGF level to 34.5 pg/mL 1 month after starting treatment. It is currently 1 year since disease onset, and although the patient has stopped taking prednisolone, there has been no recurrence of RS3PE syndrome.

Conclusions

To the best of our knowledge, this is the first reported case of a patient developing RS3PE syndrome during the clinical course of TSS. We propose that the onset mechanism involved an increase in blood VEGF due to TSS, which induced RS3PE syndrome. As serum VEGF becomes elevated with both severe infections associated with shock and RS3PE syndrome, awareness that these conditions can occur concurrently is essential.

Peer Review reports

Background

Remitting seronegative symmetrical synovitis with pitting edema (RS3PE) syndrome was first reported in 1985 by McCarty et al. [1]. It commonly occurs in elderly individuals and is “remitting,” “seronegative” (namely rheumatoid factor-negative), “symmetrical,” and characterized by synovitis with pitting edema on the dorsum of the hands and feet. Although its cause remains unknown, there have been recent reports of elevated serum vascular endothelial growth factor (VEGF) levels in this condition [2], suggesting a correlation between VEGF and RS3PE syndrome. VEGF is a factor involved in angiogenesis and vascular permeability [3]. It is elevated in inflammatory diseases such as rheumatoid arthritis (RA), ischemic processes such as the systemic inflammatory response, and wound healing, wherein it contributes to the restoration of tissue blood flow after an injury [3].

Elevated serum VEGF has also been linked with toxic shock syndrome (TSS) [4], a condition that results from infection by the toxin-producing Staphylococcus aureus or Streptococcus species [5]. These bacteria produce exotoxins, such as TSS toxin 1 and enterotoxin, which promote the activation of T-cells, resulting in a cytokine storm that can subsequently result in significant morbidity and mortality [5].

Here, we report for the first time a case of increased serum VEGF and development of RS3PE syndrome during the clinical course of TSS.

Case presentation

An 85-year-old man visited our department complaining of a rash that had appeared 2 days earlier and a fever that had developed on the day of his visit. His medical history included hypertension, aortic dissection (Stanford Type B), exertional angina, and chronic obstructive pulmonary disease (COPD). He had been prescribed the following medications, which had not changed in the previous 12 months, for his medical conditions: rosuvastatin, 2.5 mg/day; ethyl icosapentate, 1800 mg/day; valsartan, 80 mg/day; amlodipine, 5 mg/day; benidipine, 8 mg/day; bisoprolol, 2.5 mg/day; lansoprazole, 15 mg/day; clopidogrel, 75 mg/day (changed to a generic brand 1 week prior to hospital presentation); sarpogrelate, 200 mg/day; and tiotropium inhalation, 18 μg/day. Two days before presentation, the patient had also been prescribed fexofenadine (120 mg/day); however, this did not result in any improvement; instead, the rash spread from the patient’s neck and right upper arm to his entire body.

Upon presentation, the patient was conscious and lucid, and his vital signs were as follows: heart rate, 90 beats/min and regular; body temperature, 39.0 °C; blood pressure, 144/86 mmHg; respiratory rate, 24 breaths/min; and peripheral oxygen saturation, 95% on room air. Physical findings included mild conjunctiva hyperemia in both eyes, and erythema on the face, trunk, and limbs (Fig. 1). The erythema was diagnosed as erythema exudativum multiforme by the dermatologist. There was no enanthema in the oral cavity and no desquamation. The superficial lymph nodes were not palpable. However, there was reddening and swelling of the right lateral malleolus. Laboratory investigation results were as follows (Table 1): white blood cell count (WBC), 19,920/μL (neutrophils, 90.9%; lymph, 4.7%; and eosinophils, 0.4%); C-reactive protein (CRP), 22.4 mg/dL; procalcitonin, 2.09 ng/mL; creatine kinase (CK), 812 U/L; blood urea nitrogen, 22.1 mg/dL; and creatinine, 1.2 mg/dL. Blood (2 sets), urine, sputum, and right lateral malleolus wound cultures were negative. Head, chest, abdominal, and pelvic computed tomography scans, as well as abdominal and cardiac ultrasounds, were also performed to find the cause of the patient’s fever, but results of these investigations were unremarkable and did not identify a source for the patient’s fever.

Fig. 1
figure 1

The patient had generalized erythema that was present on his face (a), trunk (b), right hand (c), left lower leg (d), and right lower leg (e)

Table 1 Laboratory data on admission

After admission, we suspected that the patient’s rash was a drug eruption. The suspect drug clopidogrel was therefore switched to 100 mg/day aspirin, but the rash did not improve. Other possibilities were considered, including viral rash (herpes virus), malignant lymphoma, hemolytic streptococcal infection, and mycoplasma. However, these conditions were ruled out by various blood tests, as well as by the patient’s medical history. On day 2 in hospital, the patient developed transitory hypotension and elevated hepatic enzymes (aspartate aminotransferase, 48 U/L; and alanine aminotransferase, 50 U/L) and lactate (3.3 mmol/L; standard value: 0.56–1.39). He also developed a wheeze on the same day, which we thought was due to worsening of his underlying COPD. As such, he was treated with oral prednisolone (30 mg) for 3 days. Though this resulted in temporary improvement of his fever and a decrease in his CRP level, these variables became elevated again from day 5, and on day 7, he had desquamation on all four limbs.

As no bacteria were detected from the patient’s blood culture upon admission, and based on his clinical course of fever, erythema exudativum multiforme, transitory hypotension, conjunctiva hyperemia, elevated CK, and desquamation, we suspected TSS. We therefore started treatment with vancomycin (1 g/day) and clindamycin (600 mg/day), after which his fever rapidly remitted, and his WBC and CRP improved. Four days after starting treatment with the antibiotics, the erythema on the patient’s trunk and the rash on his lower limbs disappeared. On day 20, the patient developed membranous desquamation predominantly on his fingertips, which is characteristic of TSS (Fig. 2). Pitting edema on the dorsum of his hands and feet (Fig. 3) had also appeared around the same time as the desquamation (day 7), and the patient had painful wrist and ankle joints. Additional tests were conducted to find the cause of the edema and arthralgia, but were negative for rheumatoid factor. Anti-cyclic citrullinate protein antibodies were also found to be < 0.2. Further, serum matrix metalloproteinase-3 (MMP-3, 199.6 ng/mL; reference value, ≤123.8 ng/mL) and serum VEGF (191 pg/mL; reference value, ≤38.3 pg/mL) levels were elevated, and human leukocyte antigen (HLA)-A2 was detected (Table 2). A contrast magnetic resonance imaging (MRI) scan of the patient’s painful right wrist indicated synovial hyperplasia presenting as a low intensity signal around the carpal bone, and a contrast enhancement effect was seen in the synovial membrane with gadolinium. Similar findings were seen in the metacarpophalangeal joints including the thumb and little finger, with a contrast effect seen in the synovial membrane that was suggestive of synovitis (Fig. 4).

Fig. 2
figure 2

The rash on the patient’s trunk (a) and both lower legs (b) improved on day 10 of hospitalization. Membranous desquamation developed on both the patient’s hands on day 20 (c)

Fig. 3
figure 3

Pitting edema could be seen on the patient’s right hand (a), left hand (b), and dorsum of the right foot (c). Limb edema with remaining indentation is indicated by the red circle. Desquamation on part of the hand can also be seen

Table 2 Additional laboratory data from hospital day 10, which partly informed RS3PE syndrome diagnosis
Fig. 4
figure 4

Contrast magnetic resonance imaging of the patient’s right hand. Synovial hyperplasia presented as a low intensity signal around the carpal bone (a) and fingers (b). A contrast enhancement effect was seen with gadolinium (red circles)

Based on these findings, this case satisfied all four diagnostic criteria for RS3PE syndrome as described by Olive et al. in 1997 [2]: 1) pitting edema in the limbs, 2) acute onset, 3) patient aged 50 years or older, and 4) rheumatoid factor negativity. The patient also satisfied the auxiliary diagnostic items of elevated MMP-3 and serum VEGF levels [3], synovial imaging on contrast MRI (synovitis findings) [5], and HLA antigen positivity. He was therefore diagnosed with RS3PE syndrome, and treated with oral prednisolone (15 mg/day) from day 14. This resulted in rapid improvement of his symptoms, and he was discharged with independent performance of activities of daily living on day 31. The patient’s clinical course during hospitalization is shown in Fig. 5.

Fig. 5
figure 5

The patient’s clinical course after hospitalization. CLDM, clindamycin; CRP, C-reactive protein; VCM, vancomycin; WBC, white blood cell count

One month after starting treatment, the patient’s serum VEGF had normalized to 34.5 pg/mL. It is currently 1 year since disease onset, and though he has stopped taking prednisolone, there has been no recurrence of RS3PE syndrome.

Discussion and conclusions

This article introduced for the first time, to the best of our knowledge, a patient who developed RS3PE syndrome during the clinical course of TSS. With regard to TSS, two standards are widely used for its diagnosis: the US Centers for Disease Control and Prevention diagnostic criteria for TSS [6] and Tofte et al.’s diagnostic criteria for probable TSS [7] (Table 3). Our patient satisfied the six items of fever, diffuse erythema, characteristic desquamation on the extremities of the four limbs, reduced blood pressure, elevated CK, and conjunctival hyperemia, and was thus diagnosed with probable TSS. Furthermore, the patient satisfied all four criteria of the systemic inflammatory response syndrome (SIRS): fever, tachycardia, tachypnea, and leukocytosis. Though his fever, erythema, and limb desquamation rapidly improved with the administration of antibiotics, there was no apparent source of infection. Two months before consultation at our department however, the patient had pain and swelling from an insect bite on his right lateral malleolus. There was no abscess formation, and the cellulitis at this site was considered a possible infection source.

Table 3 Diagnostic categories of toxic shock syndrome (TSS)

The RS3PE syndrome that the patient developed during the clinical course of TSS is a disease concept that was first advocated by McCarty et al. in 1985 [1]. Though its diagnostic criteria have been described by Olive et al. [8] (Table 4 [9]), its onset mechanism remains unknown. It has also recently been reported that serum VEGF becomes elevated with RS3PE syndrome [2], suggesting a correlation between the condition and VEGF. Furthermore, peripheral blood VEGF is markedly higher with RS3PE syndrome than with the similar condition of RA, and can be decreased with steroid therapy. Thus, measuring serum VEGF could assist with RS3PE syndrome diagnosis [2, 10, 11]. Our case satisfied all of the RS3PE syndrome diagnostic criteria in that both MMP-3 and serum VEGF were elevated [12], synovial imaging was seen on contrast MRI (synovitis finding) [13], and the patient was positive for HLA-A2. He was also diagnosed with RS3PE syndrome based on edema and joint pain in both limbs and the marked improvement of his condition with steroid therapy.

Table 4 Diagnostic criteria for RS3PE syndrome [9]

In terms of the association between RS3PE syndrome and infection, tuberculosis, parvovirus B19, Streptobacillus moniliformis, Escherichia coli, Campylobacter jejuni, and Mycoplasma pneumoniae have all been listed as infections related to RS3PE syndrome [14,15,16,17]. Although there have been no reports of RS3PE syndrome developing during the clinical course of TSS thus far, elevated serum VEGF has been linked with both these conditions. In the case of infection, serum VEGF is initially mildly elevated, and becomes significantly elevated in serious conditions associated with septic shock with a concurrent reduction in VEGF receptor threshold [4]. This is thought to occur when VEGF is incorporated into the inflammatory cascade and subsequently becomes elevated through inflammation associated with severe infection, which includes ischemic processes and SIRS. This mechanism has been shown to correlate with severity scores such as the Sepsis-related Organ Failure Assessment score [4]. In our case, the patient had successive onset of the comparatively rare diseases of TSS and RS3PE syndrome. Because both are associated with elevated serum VEGF, as mentioned above, the sequential development of these conditions is not considered to be incidental. We therefore propose that serum VEGF levels are elevated with TSS as well as with hypotension-related ischemic processes, SIRS, and restoration of blood flow to the tissues after TSS, which may then have triggered RS3PE syndrome. Caution and awareness of the possibility that RS3PE syndrome may develop concurrently with severe infections associated with shock is thus essential when treating patients with conditions such as TSS.

In conclusion, to the best of our knowledge, this is the first case of a patient developing RS3PE syndrome during the clinical course of TSS. The proposed mechanism of onset is thought to have been an increase in blood VEGF due to TSS, which induced RS3PE syndrome. As serum VEGF becomes elevated with both severe infections associated with shock and RS3PE syndrome, awareness that these conditions can occur concurrently is essential.

Abbreviations

CK:

Creatine kinase

COPD:

Chronic obstructive pulmonary disease

CRP:

C-reactive protein

HLA:

Human leukocyte antigen

MMP-3:

Matrix metalloproteinase-3

MRI:

Magnetic resonance imaging

POEMS:

Polyneuropathy, organomegaly, endocrinopathy, monoclonal protein, skin changes

RS3PE:

Remitting seronegative symmetrical synovitis with pitting edema

TSS:

Toxic shock syndrome

VEGF:

Vascular endothelial growth factor

References

  1. McCarty DJ, O'Duffy JD, Pearson L, Hunter JB. Remitting seronegative symmetrical synovitis with pitting edema. RS3PE syndrome. JAMA. 254:2763–7.

  2. Arima K, Origuchi T, Tamai M, Iwanaga N, Izumi Y, Huang M, Tanaka F, Kamachi M, Aratake K, Nakamura H, Ida H, Uetani M, Kawakami A, Eguchi K. RS3PE syndrome presenting as vascular endothelial growth factor associated disorder. Ann Rheum Dis. 2005;64:1653–5.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  3. Senger DR, Galli SJ, Dvorak AM, Perruzzi CA, Harvey VS, Dvorak HF. Tumor cells secrete a vascular permeability factor that promotes accumulation of ascites fluid. Science. 1983;219:983–5.

    Article  CAS  PubMed  Google Scholar

  4. Shapiro NI, Yano K, Okada H, Fischer C, Howell M, Spokes KC, Ngo L, Angus DC, Aird WC. A prospective, observational study of soluble FLT-1 and vascular endothelial growth factor in sepsis. Shock. 2008;29:452–7.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  5. Lappin E, Ferguson AJ. Gram-positive toxic shock syndromes. Lancet Infect Dis. 2009;9:281–90.

    Article  CAS  PubMed  Google Scholar

  6. Case definitions for infectious conditions under public health surveillance. Centers for Disease Control and Prevention. MMWR Recomm Rep. 1997;46(RR-10):1–55.

  7. Tofte RW, Williams DN. Toxic shock syndrome. Evidence of a broad clinical spectrum. JAMA. 1981;246:2163–7.

    Article  CAS  PubMed  Google Scholar

  8. Olive A, del Blanco J, Pons M, Vaquero M, Tena X. The clinical spectrum of remitting seronegative symmetrical synovitis with pitting edema. The Catalan Group for the Study of RS3PE. J Rheumatol. 1997;24:333–6.

    CAS  PubMed  Google Scholar

  9. Agarwal V, Dabra AK, Kaur R, Sachdev A, Singh R. Remitting seronegative symmetrical synovitis with pitting edema (RS3PE) syndrome: ultrasonography as a diagnostic tool. Clin Rheumatol. 2005;24:476–9.

    Article  PubMed  Google Scholar

  10. Keenan RT, Hamalian GM, Pillinger MH. RS3PE presenting in a unilateral pattern: case report and review of the literature. Semin Arthritis Rheum. 2009;38:428–33.

    Article  PubMed  Google Scholar

  11. Yao Q, Su X, Altman RD. Is remitting seronegative symmetrical synovitis with pitting edema (RS3PE) a subset of rheumatoid arthritis? Semin Arthritis Rheum. 2010;40:89–94.

    Article  PubMed  Google Scholar

  12. Origuchi T, Arima K, Kawashiri SY, Tamai M, Yamasaki S, Nakamura H, Tsukada T, Aramaki T, Furuyama M, Miyashita T, Kawabe Y, Iwanaga N, Terada K, Ueki Y, Fukuda T, Eguchi K, Kawakami A. High serum matrix metalloproteinase 3 is characteristic of patients with paraneoplastic remitting seronegative symmetrical synovitis with pitting edema syndrome. Mod Rheumatol. 2012;22:584–8.

    Article  CAS  PubMed  Google Scholar

  13. Unlu Z, Orguc S, Ovali GY, Tarhan S, Dayan I, Angin A. Magnetic resonance imaging findings in a case of remitting seronegative symmetrical synovitis with pitting edema. Clin Rheumatol. 2005;24:648–51.

    Article  PubMed  Google Scholar

  14. Nicolas-Sanchez FJ, Rozadilla Sacanell JR, Gort Oromi AM, Torres Cortada G, Soler Rosell T, Sarrat-Nuevo RM, Nicolas-Sanchez ME, Cabau-Rubies J. RS3PE associated with tuberculosis. An Med Interna. 2007;24:494–6.

    CAS  PubMed  Google Scholar

  15. Perandones CE, Colmegna I, Arana RM. Parvovirus B19: another agent associated with remitting seronegative symmetrical synovitis with pitting edema. J Rheumatol. 2005;32:389–90.

    PubMed  Google Scholar

  16. Matsuda M, Shimojima Y, Gono T, Ishii W, Kaneko K, Yazaki M, Ikeda SI. Remitting seronegative symmetrical synovitis with pitting oedema/polymyalgia rheumatica after infection with mycoplasma pneumoniae. Ann Rheum Dis. 2005;64:1797–8.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  17. Drago F, Ciccarese G, Agnoletti AF, Cogorno L, Muda A, Cozzani E, Parodi A. Remitting seronegative symmetrical synovitis with pitting edema associated with parvovirus B19 infection: two new cases and review of the comorbidities. Int J Dermatol. 2015;54:e389–93.

    Article  PubMed  Google Scholar

Download references

Availability of data and materials

All data supporting our findings are contained within this published article.

Author information

Authors and Affiliations

Authors

Contributions

MK managed the case and redaction and correction of the manuscript. TK assisted with redaction, correction, and reconstruction of the manuscript. RN assisted with clinical management of the case and correction of the manuscript. HA assisted with manuscript correction and redaction of comments from the illustrations. All authors read and approved the final manuscript.

Corresponding author

Correspondence to Tsuneaki Kenzaka.

Ethics declarations

Ethics approval and consent to participate

Ethics approval and consent for this case report were waived.

Consent for publication

Written informed consent was obtained from the patient for publication of this case report and accompanying images. A copy of the written consent is available for review by the Editor of this journal.

Competing interests

The authors declare that they have no competing interests.

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Rights and permissions

Open Access This article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made. The Creative Commons Public Domain Dedication waiver (http://creativecommons.org/publicdomain/zero/1.0/) applies to the data made available in this article, unless otherwise stated.

Reprints and permissions

About this article

Check for updates. Verify currency and authenticity via CrossMark

Cite this article

Kyotani, M., Kenzaka, T., Nishio, R. et al. RS3PE syndrome developing during the course of probable toxic shock syndrome: a case report. BMC Infect Dis 18, 174 (2018). https://doi.org/10.1186/s12879-018-3089-6
