Tertiary syphilis in the lumbar spine: a case report

Abstract

Background

The incidence of tertiary syphilis involvement in the spinal column with destructive bone lesions is very rare. It is difficult to establish the correct diagnosis from radiographs and histological examination alone. Limited data are available on surgical treatment to tertiary syphilitic spinal lesions. In this article, we report a case of tertiary syphilis in the lumbar spine with osteolytic lesions causing cauda equina compression.

Case presentation

A 44-year-old man who suffered with low back pain for 6 months and progressive radiating pain at lower extremity for 1 week. Radiologic findings showed osteolytic lesion and new bone formation in the parts of the bodies of L4 and L5. Serum treponema pallidum hemagglutination (TPHA) test was positive. A surgery of posterior debridement, interbody and posterolateral allograft bone fusion with instrumentation from L3 to S1 was performed. The low back pain and numbness abated after operation. But the follow-up radiographs showed absorption of the bone grafts and failure of instrumentation. A Charcot’s arthropathy was formed between L4 and L5.

Conclusion

It is challenging to diagnose the tertiary syphilis in the spine. Surgery is a reasonable auxiliary method to antibiotic therapy for patients who suffered with neuropathy. Charcot’s arthropathy should be considered as an operative complication.

Peer Review reports

Background

Syphilis is a sexually transmitted infection disease which caused by the spirochete Treponema pallidum. The World Health Organization (WHO) estimated that 5.6 million new cases of syphilis occurred among adolescents and adults worldwide in 2012 [1]. Though the incidence of primary and secondary syphilis is still increasing these years, the incidence of tertiary syphilis had remarkable decreased due to widespread availability of effective treatment. In this report, we present a case of tertiary syphilis in the lumbar vertebra.

Case presentation

A 44-year-old man was hospitalized because of low back pain for 6 months and progressive radiating pain at lower extremity for 1 week. He had numbness below the knees, with two ankle progressively weakening and inability to walk. There was no fever, chills, cough, dyspnea, nausea and vomiting in the course of the disease. He had suffered “arthritis” in the right ankle for 6 years. Glans penis lesions were found about 8 years ago but self-healed. He has no history of tuberculosis. His vital signs were normal. The physical signs were severe limitation of all spinal movements in the lumbar region; pain on percussion over the lumbosacral area, which also produced radicular pain to lower extremity; there was partial sensory loss in the feet and distal parts of the legs; the ankle tendon reflexes were absent; the left ankle dorsiflexors power was weak; the right ankle was fixed in 90° of flexion. The straight leg raising test was bilaterally positive. The patient’s pupils, cardiovascular, pulmonary and abdominal examination were normal.

Laboratory examination showed that the white blood count, erythrocyte sedimentation rate, and C-reactive protein were normal. Serum treponema pallidum hemagglutination (TPHA) test was positive. The quantitative rapid plasma reagin (RPR) reaction of serum was positive (1:16). Cerebrospinal fluid (CSF) pressure was not elevated during lumbar puncture. The CSF had an increased protein level of 0.93 g/L, normal WBCs (5 × 106/L) and normal glucose level (4.04 mmol/L). The RPR reaction of CSF was positive (1:2). The serum brucella agglutination test was negative.

X-ray of the lumbar spine revealed narrowing of intervertebral space between L4 and L5 (Fig. 1a). X-ray of left ankle showed severe destruction and disorganization in a Charcot joint (Fig. 1b) CT scan showed osteolytic lesion and new bone formation in the parts of the bodies of L4 and L5 (Fig. 2a). Magnetic resonance imaging (MRI) displayed that bone destruction and external skeletal soft tissue formation at the L4 vertebral body level corresponding with the stenotic area (Fig. 2b).

Fig. 1
figure 1

a. X-ray of the lumbar spine revealed narrowing of intervertebral space between L4 and L5. b. X-ray of left ankle showed severe destruction and disorganisation in a Charcot joint. c. Postoperative X-ray of lumbar spine showed well fixation and bone grafting

Fig. 2
figure 2

a. CT scan showed osteolytic lesion and new bone formation in the parts of the bodies of L4 and L5. b. Magnetic resonance imaging (MRI) revealed bone destruction and extraskeletal soft tissue formation posterior at the L4 vertebral body level corresponding with the stenotic area

The patient went through a posterior debridement, interbody and posterolateral allograft bone fusion with instrumentation from L3 to S1 (Fig. 1c). During operation, an organized collection was found around the dura sac and sent for histopathological examination. Histology examination showed chronic inflamed granulation tissue, degenerate bone and fibrocartilage tissue, and necrotic tissue but indistinguishable from tuberculosis (Fig. 3).

Fig. 3
figure 3

Histology showed chronic inflamed granulation tissue, degenerate bone and fibrocartilage tissue, and necrotic tissue.H&E, original magification ×20

After operation, low back pain and lower extremity numbness abated immediately. The patient was diagnosed as neurosyphillis, resulting in tabetic arthropathy affecting spine and left ankle. Following the European guideline, he was treated with penicillin G benzathine 2.4 mU, intramusculary once a week, for 3 weeks after discharge [2]. During 3 months follow-up, the patient complained about low back pain and the numbness below the knees worsened again. Radiologic findings showed the screws were loosed, parts of bone grafts were absorbed and L4 and L5 were nonunion. After 6 months follow-up, the quantitative RPR reaction of serum was positive (1:4). But radiologic findings showed bone grafts were more absorbed. After 9 months and 12 months follow-up, radiologic findings showed bone grafts were absorbed totally and L4 move forward progressively (Fig. 4). Unfortunately, the patient died of acute hemorrhage caused by duodenal ulcer one and half year post-operation.

Fig. 4
figure 4

Lateral X-ray of the lumbar spine follow-up from postoperation 3 months, 6 months, 9 months and 12 months. It showed the screws were loosed and bone grafts were absorbed gradually. There is a Charcot’s arthropathy between L4 and L5. PO, postoperation

Discussion

Syphilis is a multistage disease which is usually transmitted through sexual contact or mother-infant transmission route. The incidence of syphilis has significantly decreased by penicillin treatment during the primary and secondary stages of the disease [3, 4]. Tertiary syphilitic occurs approximately 3 to 15 years after initial infection [5]. Syphilitic involvement in the spinal column is very rare. The incidence of tertiary syphilis in the spine is not clear because this form of syphilitic complication has been documented only in occasional case reports [6,7,8,9].

The diagnosis of syphilis is facilitated by accurate and specific serological tests nowdays. But it is difficult to diagnose only with imaging and histology tests. Radiologic appearance of syphilitic spinal involvement may be misleading and resemble tuberculosis, brucellosis, degenerative osteoarthritis, or metastases [10]. Abnormal appearances on radiographs include osteophytosis, subchondral sclerosis, subluxation and soft tissue swelling. Long-term neuroarthropathy is characterized by joint dislocation [11]. It is not clear of the pathophysiology mechanism for such changes. The formation of chronic gummas is the character of gummatous syphilis. The occurrence of a gumma in bone, which is soft, tumor-like, usually causes the reactive sclerosis typical of many bony lesions. Occasionally a pure destructive lesion may be seen [12].

Up to now, T.pallidum remains sensitive to penicillin and no resistance report. However, Longer treatment duration is required for patients because the penetration of benzathine penicillin across the blood-brain barrier is poor [13]. Doxycyline or amoxicillin plus probenecid is the second line therapy option for Penicillin allergy or parenteral treatment refused [8]. However, limited data are available on efficacy of surgical treatment for tertiary syphilitic spinal lesions [7, 8, 14, 15]. Charcot’s arthropathy is one of the complicated complications and notorious to treat with or without surgical treatment [7, 11]. In our case, Charcot’s arthropathy was formed gradually even with radical debridement and interbody and posterolateral allograft bone fusion with instrumentation for destructive lesions.

Conclusions

Our case indicates a probability of a growing number of cases presenting tertiary syphilis in the spine. It is challenging to diagnose the tertiary syphilis in the spine. Surgery is a reasonable auxiliary method to antibiotic therapy for patients who suffered with neuropathy. Charcot’s arthropathy should be considered as an operative complication.

Abbreviations

RPR:

Rapid plasma regain

TPHA:

Treponema pallidum hemagglutination

References

  1. Newman L, Rowley J, Vander Hoorn S, Wijesooriya NS, Unemo M, Low N, Stevens G, Gottlieb S, Kiarie J, Temmerman M. Global estimates of the prevalence and incidence of four curable sexually transmitted infections in 2012 based on systematic review and global reporting. PLoS One. 2015;10(12):e0143304.

    Article  PubMed  PubMed Central  Google Scholar

  2. Janier M, Unemo M, Dupin N, Tiplica GS, Patel R. 2014 European guideline on the management of syphilis: giving evidence priority. J Eur Acad Dermatol Venereol. 2016;30(10):e78–9.

    Article  CAS  PubMed  Google Scholar

  3. Dourmishev LA, Dourmishev AL. Syphilis: uncommon presentations in adults. Clin Dermatol. 2005;23(6):555–64.

    Article  PubMed  Google Scholar

  4. Hercogova J, Vanousova D. Syphilis and borreliosis during pregnancy. Dermatol Ther. 2008;21(3):205–9.

    Article  CAS  PubMed  Google Scholar

  5. Kent ME, Romanelli F. Reexamining syphilis: an update on epidemiology, clinical manifestations, and management. Ann Pharmacother. 2008;42(2):226–36.

    Article  CAS  PubMed  Google Scholar

  6. Hannuksela M, Karaharju EO. Syphilis of the spine. Br J Vener Dis. 1972;48(5):397–9.

    CAS  PubMed  PubMed Central  Google Scholar

  7. Radhakrishnan K, Vijayan VP, Ashok PP, Sridharan R, Mousa ME. Syphilitic spinal neuroarthropathy with paraplegia. Clin Neurol Neurosurg. 1985;87(1):61–4.

    Article  CAS  PubMed  Google Scholar

  8. Salem KM, Majeed H, Bommireddy R, Klezl Z. Tertiary syphilis in the cervical spine: a case report and review of the literature. Global spine journal. 2013;3(1):41–6.

    Article  CAS  PubMed  Google Scholar

  9. Magaro M, Zoli A, Altomonte L, Mirone L, La Sala L, Romani M. Vertebral involvement in tertiary syphilis. Br J Rheumatol. 1990;29(5):405–6.

    Article  CAS  PubMed  Google Scholar

  10. Schotanus M, Dorleijn DM, Hosman AJ, Huits RM, Koopmans PP, Galama JM. A patient with multifocal tabetic arthropathy: a case report and review of literature. Sex Transm Dis. 2013;40(3):251–7.

    Article  PubMed  Google Scholar

  11. Park YH, Taylor JA, Szollar SM, Resnick D. Imaging findings in spinal neuroarthropathy. Spine (Phila Pa 1976). 1994;19(13):1499–504.

    Article  CAS  Google Scholar

  12. Johns D. Syphilitic disorders of the spine. Report of two cases. J Bone Joint Surg Br. 1970;52(4):724–31.

    CAS  PubMed  Google Scholar

  13. Kingston M, French P, Goh B, Goold P, Higgins S, Sukthankar A, Stott C, Turner A, Tyler C, Young H. UK National Guidelines on the Management of Syphilis 2008. Int J STD AIDS. 2008;19(11):729–40.

    Article  CAS  PubMed  Google Scholar

  14. Griffiths RW, Rose MJ. Acute vertebral collapse and cauda equina compression in tertiary syphilis. J Neurol Neurosurg Psychiatry. 1975;38(6):558–60.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  15. Ramani PS, Sengupta RP. Cauda equina compression due to tabetic arthropathy of the spine. J Neurol Neurosurg Psychiatry. 1973;36(2):260–4.

    Article  CAS  PubMed  PubMed Central  Google Scholar

Download references

Acknowledgements

We would like thank Dr. Gang Tian for taking care of this patient. We also thank the patient’ s family for providing consent for this case report.

Funding

There were no funding sources for this article.

Availability of data and materials

All data concerning the case are presented in the manuscript.

Author information

Authors and Affiliations

Authors

Contributions

YB conceived the study, carried out most of the data collection, and drafted the manuscript. FN participated in the surgery and revised the manuscript. LDL participated in the surgery and collected the data. HS collected the data and revised the manuscript. YMW acquired and interpreted the data. SZ conceived the study, participated in the data collection and revised the manuscript. All authors read and approved the final manuscript.

Corresponding author

Correspondence to Song Zhao.

Ethics declarations

Ethics approval and consent to participate

Not applicable.

Consent for publication

A written informed consent was obtained from the patient for publication of this case report and any accompanying images.

Competing interests

The authors declare that they have no competing interests.

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Rights and permissions

Open Access This article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made. The Creative Commons Public Domain Dedication waiver (http://creativecommons.org/publicdomain/zero/1.0/) applies to the data made available in this article, unless otherwise stated.

Reprints and permissions

About this article

Check for updates. Verify currency and authenticity via CrossMark

Cite this article

Bai, Y., Niu, F., Liu, L. et al. Tertiary syphilis in the lumbar spine: a case report. BMC Infect Dis 17, 513 (2017). https://doi.org/10.1186/s12879-017-2620-5
